Specifications ]
| PROCESSOR |
|
 |
AMD® Athlon™
/Duron™ (K7) Socket A processor (256K/64K 2nd cache on
die) |
|
Supports 500MHz ~ 1GHz and faster |
|
95*/100/105*/110*/113*/115*/117*/133* MHz FSB |
|
AUTO detect CPU voltage |
CHIPSET |
|
|
VIA VT8363 (KT133) Memory/AGP/PCI Controller (PAC) |
|
VIA VT82C686B PCI Super-I/O Integrated Peripheral Controller (PSIPC) |
|
Creative CT5880 PCI sound chip (4 channel audio) |
|
AC97 codec |
MEMORY |
|
|
3 168-pin DIMM sockets |
|
Supports PC-100 / PC-133 SDRAM and VCM SDRAM |
|
Supports up to 1.5GB DRAM |
|
Supports only 3.3V SDRAM DIMM |
SLOT | |
|
1 x AMR (Audio Modem Riser) slot |
|
1 x AGP slot supports 4X mode & AGP 2.0 compliant |
|
5 x PCI slots support 33MHz & PCI 2.2 compliant |
|
1 x ISA slot |
I/O  |
|
|
2 x Ultra DMA 33/66/100 bus master IDE ports on board |
|
1 x FDD, 2 x COM, 1 x LPT, PS/2 keyboard, PS/2 Mouse on board |
|
1 x Joystick, 1 x Line-in, 1 x Line-out, 1 x MIC on board |
|
2 x USB ports on board |
|
2 x USB ports by cable (optional accessory) |
|
IrDA TX / RX header ready |
POWER |
|
|
ATX power connector |
|
Power-on by LAN, RTC, Modem & switch |
|
Power-off by Windows® 95/98/2000 Shut down & Switch |
|
Stop CPU fan during entering suspend mode |
FORM FACTOR |
|
|
ATX , 4 layer PCB (30.4*22.7cm) |
H/W MONITORING |
|
|
CPU/System fan revolution detect |
|
CPU/System temperature detect |
|
System voltage detect (Vcore, VDD ,Vcc, +12V) |
|
CPU overheat shutdown detect |
BIOS  |
|
|
Supports DualBIOS™ technology; 2Mbit flash RAM |
|
AMI BIOS with enhanced ACPI feature for PC98/Win98/Win2000 compliance, Green, PnP, DMI, INT13 (>8.4GB) & Anti-Virus functions |
|
IDE#1~#4, SCSI, LS120, ZIP & CD-ROM bootable |
|
AC recovery ON/OFF control |
|
Auto-detect & report system health status |
|
Supports @BIOS® Live Update |
OTHER FEATURES |
|
|
Support
Wake-On-LAN (WOL) |
|
Support Internal/External modem ring on |
|
Support USB K/B or mouse wake up from S3 |
|
Includes 3 fan power connectors |
|
Poly fuse for keyboard over-current protection |
|
Support STR (Suspend-To-RAM) function |
|
Supports EasyTune III® |
DRIVER |
|
|
Gigabyte Windows Utility Manager |
|
VIA 4 in 1 service pack utility |
|
Creative PCI sound driver |
