Specifications ]
| PROCESSOR |
|
 |
Socket A for AMD®
-K7 Athlon™ & Duron™ 200MHz FSB
processors |
|
90*/95*/100/105*/110*/115* MHz FSB |
|
AUTO detect CPU voltage |
CHIPSET |
|
|
AMD® 751 (Irongate) North Bridge |
|
AMD® 756 (Viper) South Bridge |
|
Winbond W83977 I/O set |
|
Winbond W83782 health chip |
MEMORY |
|
|
16MB to 768MB DRAM size |
|
3 x 3.3V DIMM sockets |
|
Supports 64/128/256 MB SDRAM DIMM module |
|
Supports ECC type DIMM module (72bits) |
SLOT | |
|
1 x AGP slot supports 2X mode |
|
5 x PCI slots support 33MHz & PCI 2.2 compliant |
|
2 x ISA slots |
I/O  |
|
|
2 x Ultra DMA 33/66 Bus Master IDE ports on board |
|
1 x FDD, 2 x COM, 1 x LPT, PS/2 Keyboard, PS/2 Mouse on board |
|
2 x USB ports on board |
|
2 x USB ports by cable (optional accessory) |
|
IrDA TX / RX header |
POWER |
|
|
ATX power connector |
|
Power-on by K/B, PS/2 Mouse, LAN, RTC, modem & switch |
|
Power-off by Windows® 95/98/2000 Shut down & Switch |
|
AC Recovery ON/OFF control |
|
3 level ACPI LED support |
|
Stop CPU fan during entering suspend mode |
FORM FACTOR |
|
|
ATX , 4 layer PCB (30.5*20.8cm) |
H/W MONITORING |
|
|
Auto speed down and alarm when CPU overheat or fan failure (OS independent & driverless) |
|
3 fan power & speed detection connectors |
|
Case open detection |
|
System health status detect & report by Gigabyte Windows Utility Manager |
|
H/W detect ¡Ó5V, ¡Ó12V, CPU voltage & CMOS battery status |
BIOS |
|
|
2Mbit flash RAM |
|
AMI BIOS with enhanced ACPI feature for PC98/Win98/Win2000 compliance, Green, PnP, DMI, INT13 (>8.4GB) & Anti-Virus functions |
|
IDE#1~#4, SCSI, LS120, ZIP & CD-ROM bootable |
|
Auto-detect & report system health status |
OTHER FEATURES |
|
|
Includes Wake-On-LAN header (WOL) |
|
Includes Wake-On-Ring (WOR) |
|
Poly fuse for keyboard & USB over-current protection |
DRIVER |
|
|
Gigabyte Windows Utility Manager |
|
AMD® AGP miniport driver |
|
AMD® bus master IDE driver, supports UDMA 33/66 |
