[ Specifications ]

PROCESSOR
	Dual Socket 370 for Intel® FC-PGA Pentium® III or other compatible processors(1)
	66*/100/112*/124*/133/142*/152* MHz FSB
	AUTO detect CPU voltage
CHIPSET
	VIA Apollo Pro Family AGPset
MEMORY
	4 168-pin DIMM sockets
	Supports PC-100 / PC-133 SDRAM and VCM SDRAM
	Supports up to 1.5GB DRAM
	Supports only 3.3V SDRAM DIMM
SLOT
	1 x AGP slot supports 4X mode & AGP 2.0 compliant
	5 x PCI slots support 33MHz & PCI 2.2 compliant
	1 x ISA slot
I/O
	2 x Ultra DMA 33/66 bus master IDE ports on board/ 2 x Ultra DMA 66/100 Bus Master IDE ports on board (for revision 5.0 only)
	1 x FDD, 2 x COM, 1 x LPT, PS/2 keyboard, PS/2 Mouse on board
	2 x USB ports on board
	2 x USB ports by cable (optional accessory)
	IrDA TX / RX header ready
POWER
	ATX power connector
	Power-on by LAN, RTC, Modem & switch
	Power-off by Windows® 95/98/2000 shut down & switch
	Stop CPU fan during entering suspend mode
FORM FACTOR
	ATX , 4 layer PCB (30.4*24.3 cm)
H/W MONITORING
	CPU/System fan speed detect
	CPU/System temperature detect
	System voltage detect (Vcore, VDD ,Vcc, +12V)
	CPU overheat shutdown detect
BIOS
	2Mbit flash RAM
	AMI BIOS with enhanced ACPI feature for PC98/Win98/Win2000 compliance, Green, PnP, DMI, INT13 (>8.4GB) & Anti-Virus functions
	IDE#1~#4, SCSI, LS120, ZIP & CD-ROM bootable
	AC recovery ON/OFF control
	Auto-detect & report system health status
OTHER FEATURES
	Support Wake-On-LAN (WOL)
	Support Internal/External modem ring on
	Support USB K/B or mouse wake up from S3
	Includes 4 fan power connectors
	Poly fuse for keyboard over-current protection
	Support STR (Suspend-To-RAM) function(2)
DRIVER
	Gigabyte Windows Utility Manager
	VIA 4 in 1 service pack utility
The specification and pictures are subject to change without notice. All trademarks and logos are the properties of their respective holders.. *These speed settings are not guaranteed by GIGABYTE
