Specifications ]
| PROCESSOR |
|
 |
Socket 370 for Intel®
and other compatible processors |
|
Supports CPU multiplier 3.0~8.0 for future processors |
|
Auto/66/75*/83*/100/112*/124*/133/140*/150* MHz FSB |
|
AUTO Detect CPU Voltage |
CHIPSET |
|
|
VIA Apollo Pro Family AGPset; AC97 codec |
DRAM |
|
|
8MB to 1.5GB SDRAM size |
|
3 x 3.3V DIMM sockets |
|
Supports 8/16/32/64/128/256/512 MB SDRAM DIMM module |
|
Supports ECC type DIMM module (72bits) |
SLOT | |
|
1 x AMR (Audio Modem Riser) slot |
|
1 x AGP slot supports 2X / 4X mode |
|
5 x PCI slots support 33MHz & PCI 2.2 compliant |
|
1 x ISA slot |
I/O  |
|
|
2 x Ultra DMA 33/66 Bus Master IDE ports on board |
|
1 x FDD, 2 x COM, 1 x LPT, PS/2 Keyboard, PS/2 Mouse on board |
|
1 x Joystick, 1 x Line-in, 1 x Line-out, 1 x MIC on board |
|
2 x USB ports on board |
|
2 x USB ports by cable (optional accessory) |
|
IrDA TX / RX Header ready |
POWER |
|
|
ATX power connector |
|
Power-on by LAN, RTC, Modem & Switch |
|
Power-off by Windows® 98 shut down & Switch |
|
Wake-up by USB device |
|
Suspend / Wake-on by ACPI & APM device |
|
AC recovery ON/OFF control; 3 level ACPI LED support |
|
Stop CPU fan during entering suspend mode |
FORM FACTOR |
|
|
ATX , 4 layer PCB (30.5*20.3 cm) |
H/W MONITORING |
|
|
Auto speed down
and alarm when CPU overheat or fan failure (OS independent & driverless) |
|
3 fan power & speed detection connectors |
|
System health status detect & report by BIOS |
|
H/W detect +5V, +12V, CPU voltage & CMOS battery status |
BIOS |
|
|
2Mbit flash RAM |
|
AMI BIOS with enhanced ACPI feature for PC98/Win98 compliance, Green, PnP, DMI, INT13 (>8.4GB) & Anti-Virus functions |
|
IDE#1~#4, SCSI, LS120, ZIP & CD-ROM bootable |
OTHER FEATURES |
|
|
Suspend-To-RAM
(STR) |
|
Includes Wake-On-LAN header (WOL); Includes Wake-On-Ring (WOR) |
|
Supports Internal / External modem wake on |
|
Poly fuse for keyboard, USB & game overcurrent protection |
DRIVER |
|
|
VIA Ultra DMA 33/66 Bus Master IDE driver |
|
VIA AGP GART VxD & power management controller driver |
|
VIA patch 95 driver |
|
VIA Windows® 98 IRQ routing driver |
