[ WB6 ] - Slot 1 Based PC 99 All-in-One Mainboard

[ WB6 Pentium^® III PC99 All-In-One Mainboard With SOFT MENU^TM II Technology ]
ABIT's latest, the WB6, is designed with the Intel's value-oriented 810E chipset with integrated with a high performance 3D graphics accelerator. ABIT brings the power and value of the Intel 810E chipset with the Slot 1 platform to provide a tremendously powerful yet cost efficient solution. The WB6 supports the most advanced Jumperless technology, SoftMenu^TM II which provides ABIT's customers the easiest and safest environment to achieve maximum performance.

[ Specifications ]

CPU
1. Supports Intel Pentium^® III 450~733MHz processor cartridge
2. Supports Intel Pentium^® II 300~450MHz processor cartridge
3. Supports Intel Celeron^TM 266~500MHz processor
4. Reserves support for future Intel Pentium^®III processors

Chipset
1. Intel^®810E chipset supports 66/100/133MHz Front Side Bus
2. Supports Ultra DMA33/66 IDE protocol
3. Supports Advanced Configuration and Power Management Interface (ACPI)

Memory
1. Two 168-pin DIMM sockets support SDRAM module
2. Supports up to 512MB (8, 16, 32, 64, 128,256MB SDRAM)

Graphics
1. Chipset integrated AGP 2X 3D graphics accelerator
2. 133MHz Dynamic Display Memory Interface
3. On board 4MB SDRAM Graphics Memory
4. Optional TV output adapter

Audio
1. AC'97 2.1 Audio CODEC on board
2. AC'97 Digital Audio controller integrated in ICH

System BIOS
1. Award Plug and Play BIOS supports APM, DMI and ACPI
3. Write-Protect Anti-Virus function by AWARD BIOS
3. 4M-bit Flash ROM
4. Year 2000 Compliant

Multi I/O Functions
1. 1x Floppy Port (up to 2.88MB floppy drive) for two floppy devices
2. Two Channels of bus Master IDE Ports supporting up to four Ultra DMA 33/66 devices
3. 1x Parallel Port
4. 1x Serial Port
5. PS/2 Keyboard and PS/2 Mouse Connectors
6. 2x USB Connectors
7. IrDA TX/RX header
8. Wake on LAN header
9. Wake on Ring header
10. VGA connector
11. Audio connector(Line-in, Line-out, Mic-in, and Game Port)

Hardware Moinitoring
1. Hardware monitoring - Included fan speed, voltages, CPU and system environment temperature
2. Built-in Thermal Sensor to detect CPU and System temperature

Miscellaneous
1. Micro ATX form factor
2. Three PCI slots and One AMR slot
3. Supports Keyboard and Mouse Power On
4. Supports Suspend to RAM (STR) function
5. PC99 Compliant
6. Dimensions : 240*195mm
