[ BX6 PentiumŽIII AGP Based ATX Mainboard With CPU SOFT MENUTM II Technology ]
This is ABIT's premier
all around full spec 440BX motherboard. 440BX is the new high-end chipset
for the Pentium® II from Intel.
It has all the features found on ABIT's 440LX motherboards, but with the
added benefit of being able to support the new Pentium®
II CPUs with the 100MHz external CPU clock. Better yet, this motherboard
is backwards compatible to support all Pentium®
II CPU's currently on the market. That means that you can use your current
Pentium® II CPU with the BX6 and
get a performance boost from all the latest features found on Intel's
440BX chipset. Plus benefit from ABIT's new Soft MenuTM
II which allows for the first time ever, voltage changing for Pentium®
II CPUs, plus faster boot times over the Soft Menu original, and the standard
feature of hardware temperature monitoring.
[
Specifications ]
CPU
1. Supports Pentium®II 350~450MHz processors cartridge
(based on 100MHz clock). 2.Supports Pentium®II 233~333MHz
processors cartridge (based on 66MHz clock). 3.Supports Celeron®
266~333MHz processor cartridge (Based on 66MHz clock)
Chipset
1. Intel440BX chipset (82443BX and 82371EB)
2. Supports Ultra DMA/33 IDE protocol
3. Supports Advanced Configuration and Power Management Interface (ACPI)
4. Supports AGP 66/133
MHz (Sideband) 3.3V device
Memory
1. Four 168-pin DIMM sockets support SDRAM modules
2. Supports up to 512MB max (8, 16, 32, 64,
128MB SDRAM)
3. ECC support
System BIOS
1. CPU SOFT MENUTM II eliminates
the need for jumpers or DIP switches needed to set CPU parameters
2. Award Plug and Play BIOS supports APM,
DMI, and ACPI
3. Write-protect Anti-Virus function by AWARD BIOS
4. Year 2000 compliant
Functions
1. One floppy port connector supporting up to 2.88MB floppy drive and
3 mode floppy drive
2. Two channels of bus master IDE ports connectors for up to four IDE
devices (including LS-120MB floppy drive)
3. One built-in Standard/EPP/ECP parallel
port connector
4. Two built-in 16550 compatible serial ports connectors
5. Built-in PS/2 keyboard and PS/2 mouse ports connectors
4. Two built-in USB ports connectors
Miscellaneous
1. ATX form factor
2. One AGP slot, Four
PCI slots, Three ISA slots
3. Hardware monitoring - Including fan speed,
voltages, and system environment temperature
4. Dimensions : 305*245mm
