| SPECIFICATION |
| Processor |
- Support Socket-A for
AMD Athlon /Duron TM uni-proccessor at 266MHz Front
Side Bus with double data rate
|
| Chipset |
- VIA
Apollo KT266A(VT8366A)
System controller and VT8233A
High Bandwidth Vlink Client South Bridge
|
| CPU
Bus Frequency |
- CPU Bus Frequency ,
Choose One Step Add 1MHz From 100MHz Up to 200MHz in
BIOS Setup (Frequency Magic Setting)
|
| Jumpless |
- Support Jumpless
Function by BIOS SETUP Let Users More Easier to Change
The Frequency
|
| Expansion
Slot |
- Five 32-bit PCI Bus
Master slots
- One CNR (Communication
Network Raiser) Slot
|
| System
Memory |
- 2 x 168-pin DIMM
Sockets support PC133/PC100 SDRAM up to 2.0GB System
Memory.
- 2 x 184-pin DDR Module
Socket support DDR200/DDR266 DDR SDRAM up to 2.0GB
System memory.
|
| On
Board IDE |
- Support 2 X IDE
Connectors for up to 4 IDE Drives
- Support PIO Mode 3 and
Mode 4 and Bus Master IDE DMA, Mode 4 Timing for up to
16M Bytes/s
- Support UTRA DMA-133
Bus Master IDE, Provide faster transfer rate up to
100M Bytes/s
- Support LS-120 / ZIP
Device
|
| AGP
SLOT |
- Support 4X AGP VGA Mode
for 266MHz of AD and SBA signaling
- Pipelined split
transaction long-burst transfers up to 1GB/sec
|
| On
Board 3D Audio |
- Software Audio
Controller With On Board CODEC Complete to AC97'
- Support 3D Surround
- Support 3D Positioning
- Full Duplex Operation
For Simultaneous Record And Playback
- Sound Driver for
Windows 95 , Windows98 & Windows NT4.0 , Media
Rack
|
| On
Board Ultra I/O |
- 2 X Serial Ports (16550
Fast UART Compatible)
- 1 X Parallel Port (EPP
and ECP capabilities)
- 1 X Floppy Disk
Connector (Supports 2 Floppy Drivers)
- 1 X PS2 Mouse Connector
- 1 X Keybord Cnnector
- 2 X Three Wire FAN
Connector (Include CPU FAN)
- 1 X LINE IN / LINE OUT
/ Microphone Connector
- 1 X Game Port Connector
(Support Two Joysticks)
- 2 X Analog Audio CD
Music line Connectors (different connector)
- 1 X Consumer IR
Connector
- 1 X Standard IR
Connector (Infrared)
|
| VIA
Health Monitor |
- VIA Hareware Monitoring
to Track CPU & SYSTEM Temperature, Voltage, Fan
speed, Monitoring your Computer
- Driver For Win95/98 and
NT4.0
|
| On
Board USB |
- 6 X USB Ports Connector
- Support USB Keyboard
& USB Mouse
|
| Power
Saving |
- ACPI/APM Power
Management
- Modem Ring remote wake
up
- RTC Alarm Wake up
- Support Software
Suspend & Power off
- Wake on LAN For OS
- Support Power Button
Ride (Instant off or Delay 4 second power off)
|
| Power
Supply |
- Support 20-pin ATX
power supply (ATX-PW)
|
| BIOS |
- Award BIOS , Support
Green function, Plug and Play Function
- 2MBit Flash ROM
|
| Dimension |
- ATX Form Factor with
30.5cm X 24.4cm
|
