| FEATURES |
| Support Intel PentiumÒ
II / III And CeleronTM Slot 1 Processor |
| Support Socket 370 For Intel
CeleronTM PPGA/FCPGA Processor |
| VIA 82C694X , 82C596B 133MHZ
Chipset |
| On Board CMI8738 PCI 3D Audio
Chipset (For 994AS-L) |
| Support 66/75/83/100/112/124/133/140
MHz Bus Frequency For CPU Host Clock |
| Support Ultra DMA 66 Mode |
| Support PC HEALTH MONITOR III
|
| Support 3 Banks of DRAM From
8Mbyte to 1.5GByte Main Memory |
| PC'99 Ready & PC'99 Colourful
I/O Ports Design |
| Support USB Controller & PS/2
Mouse , Standard IR (infrared) Function |
| Provide extra " three-wire"
fans connectors |
| Y2K Compliant |
- Modem Ring remote wake up
- Power Button Ride (Instant off or Delay
4 second power off)
- RTC alarm wake up
- Wake on LAN For OS
- Support software suspend & power off
(Windows 95 or Windows98)
|
| SPECIFICATION |
| Processor |
- Intel PentiumÒII
/ III , CeleronTM Slot1 Processor Optimised For 100 / 133
MHz Front Side Bus Frequency
- Socket 370 For Intel CeleronTM
PPGA/FCPGA Processor
- Can't Use Slot1 And Socket 370 Processor
Together
|
| Chipset |
- VIA 82C694X / 82C596B 133MHz Chipset
- CMI8738 PCI 3D Audio Chipset (For 994AS-L)
|
| CPU Bus Frequency |
- Support Jumper Select 66.7/100/133
MHZ CPU Bus Frequency Default Selection
- CPU Bus Frequency , Choose 66 / 75
/ 83 / 100 / 103 / 112 / 124 / 133 /140 MHZ in BIOS Setup
- Jumper setting Selection CPU Ratio
From 2X to 8X
|
| AGP SLOT |
- Support 4X AGP VGA Mode for 266MHz of
AD and SBA signalling
- Pipelined split transaction long-burst
transfers up to 1GB/sec
|
| Expansion
Slot |
- Four 32-bit PCI Bus Master Slots
- One 16-bit ISA Bus Slot
|
| System
Memory |
- Support 3 Banks of SDRAM From 8MByte
to 1.5GByte
- 3 X 168-pins DIMM Sockets (3.3V)
- Support EDO (66MHz Only) & SDRAM (66MHz/100MHz/133MHz)
- Support ECC or Parity Check
|
| On Board
IDE |
- Support 2 X IDE Connectors for
up to 4 IDE Drives
- Support PIO Mode 3 and Mode 4 and Bus
Master IDE DMA, Mode 4 Timing for up to 16M Bytes/s
- Support " Ultra DMA 66 " Synchronous
DMA Mode transfer rate up to 66M Bytes/s
- Support LS-120 / ZIP Device
|
| On Board
3D Audio |
- On Board CMI8738 PCI 3D Audio Chipset
- HRTF-Base 3D Positional Audio
- Support Direct Sound TM
3D And A3D Interface
- Support Rear Side Speakers , C3DX Positional
Audio in 4CH Speaker Mode
- DLS-Base Wavetable Music Synthesizer
, Supports Direct Music TM
- Professional Digital Audio Interface
Supporting 24-Bit SPDIF IN And OUT
- Drivers Support AC3 Ò 5.1CH
Interface
- MPU-401 , Dual Game Port , 16 Bit Full
Duplex CODEC
- Support MP3 File Playback
- Sound Driver for Windows 95/98 , Windows
2000 & Windows NT4.0 , Media Rack
|
| On Board
Ultra I/O |
- PC'99 Colourful I/O Ports Design
- 2 X USB Connectors
- 1 X Standard IR Connector (SIR)
- 2 X Serial Ports (16550 Fast UART Compatible)
- 1 X Parallel Port (EPP and ECP Capabilities)
- 1 X Floppy Disk Connector (Supports
2 Floppy Drives)
- 1 X PS2 Mouse / PS2 Keyboard Connector
- 1 X Two Wire FAN Connector (Include
CPU FAN)
- 1 X LINE IN Connector (For 994AS-L)
- 1 X LINE OUT Connector (For 994AS-L)
1 X MIC Connector (For 994AS-L)
- 1 X Game Port Connector (Support Two
Joysticks , For 994AS-L)
- 1 X SPDIF IN And OUT Connector (For
994AS-L)
- 1 X Panasonic Analogue Audio CD Music
line Connectors (For 994AS-L)
- 1 X Sony Analogue Audio CD Music line
Connectors (For 994AS-L)
|
| PC Health Monitor IIII |
- Winbond 83783 Chipset
- PC Health Monitor III to Track CPU
& SYSTEM Temperature, Voltage, Fan speed, Monitoring your Computer
|
| Power
Saving |
- ACPI/APM Power Management
- Modem Ring Remote Wake up
- RTC Alarm Wake up
- Support Software Suspend & Power off
(Windows 95/98)
- Wake on LAN For OS
- Support Power Button Ride (Instant
off or Delay 4 second power off)
|
| Power
Supply |
- Support 20-pin ATX power supply
(ATX-PW)
|
| BIOS |
- Award BIOS , Support DMI , Green ,
P&P Function
- 2MByte Flash ROM
- Support Full Screen Logo
|
| Dimension |
- ATX Form Factor with 30.5cm X 19cm
|
