1. Modem Ring remote wake up
2. ATX power supply connector for Software Suspend & Show Down power off
3. Power Button Over Ride
4. RTC Alarm Wake up

• Slot 1 For Intel PentiumÒII / III , Celeron^TMProcessor Optimised For 100MHz Front Side Bus Frequency
• Socket 370 For Intel Celeron^TM PPGA/FCPGA Processor

• SIS 620 / SIS 5595 Chipset (Including 6326 AGP VGA Graphic Accelerator)
• On Board CMI8738 PCI 3D Sound Chip

• Support Jump Adjust 66.7/100 MHZ CPU Bus Frequency Default Selection
• BIOS Adjust CPU/SDRAM Bus Frequency , Include 66/66MHZ , 75/75MHZ , 83/83MHZ , 100/100MHZ , 112/112MHZ , 124/124MHZ
• BIOS Adjust CPU Ratio Selection For 2 , 2.5 , 3 , 3.5 , 4 , 4.5 , 5 , 5.5 , 6 , 6.5 , 7 , 7.5 , 8

• Support Jumperless Function by BIOS SETUP Let Users More Easier to Change The Frequency And Ratio

• One 16-bit ISA Bus Slots
• Three 32-bit PCI Bus Master slots

• Support 2 Banks of SDRAM from 8Mbyte to 1GByte Main Memory
• 2 X 168-pins DIMM Sockets

• Support 2 X IDE Connectors for up to 4 IDE Drives
• Support PIO Mode 3 and Mode 4 and Bus Master IDE DMA, Mode 4 Timing for up to 16M Bytes/s
• Support ULTRA DMA-33/66M Bus Master IDE, Provide faster transfer rate up to 33M/66M Bytes/s
• Support LS-120 / ZIP Device

• Support Direct Memory Access Shared Memory Area From 2MB to 8MB Selected by BIOS SETUP
• Support 64 Bit Memory Data Bus Interface
• Integrated a High Performance and High Quality 3D Engine
• Support AGP Spec. 1.0 Compliant , 1XMode (66MHz) , 2XMode (133MHz)
• Integrated Programmable 24-Bit Ture-Color RAMDAC up to 240 MHz Pixel Clock

• On Board CMI8738 PCI 3D Audio Chipset
• HRTF-Base 3D Positional Audio
• Support Direct Sound TM 3D And A3D Interface
• Support Rear Side Speakers , C3DX Positional Audio in 4CH Speaker Mode
• DLS-Base Wavetable Music Synthesizer , Supports Direct Music TM
• Professional Digital Audio Interface Supporting 24-Bit SPDIF IN And OUT
• Drivers Support AC3 Ò 5.1CH Interface
• MPU-401 , Dual Game Port , 16 Bit Full Duplex CODEC
• Support MP3 File Playback
• Sound Driver for Windows 95/98 , Windows 2000 & Windows NT4.0 , Media Rack

• 2 X Serial Ports (16550 Fast UART Compatible)
• 1 X Parallel Port (EPP and ECP capabilities)
• 1 X Floppy Disk Connector (Supports 2 Floppy Drivers)
• 1 X PS2 Mouse Connector
• 1 X Keyboard Connector
• 2 X Three Wire CPU FAN Connector
• 1 X LINE IN / LINE OUT Connector
• 1 X Game Port Connector (Support Two Joysticks)
• 2 X Analogue Audio CD Music line Connectors (different connector)
• 1 X Standard IR Connector (Infrared)
• 1 X VGA Connector

• SIS Health Monitor to Track CPU Temperature, Voltage, Fan speed , Monitoring your Computer
• Utility For Win95/98

• 2 X USB Ports Connector
• Support USB Keyboard & USB Mouse

• ACPI/APM Power Management
• Modem Ring remote wake up
• RTC Alarm Wake up
• CPU Fan Auto-Stopping in Suspend Mode
• Support Software Suspend & Power off (Windows95 or Windows98)
• Wake on LAN For OS
• Support Keyboard Password Power on Function
• Support Power Button Ride (Instant off or Delay 4 second power off)

• Efficient PWM switching power instead of traditional Linear Voltage Regulator to Prevent Power Component From Being Burned-out

• Support 12-pin standard AT power supply (AT-PW)
• Support 20-pin ATX power supply (ATX-PW)

• Award Plug and Play and Green Function
• 2MByte Flash ROM

• Baby AT Form Factor with 22cm X 25cm
