FEATURES
Support
Socket 478B processor for Intel PentiumÒ 4 (mPGA478) package processor
,Support 400MHz System Bus Frequency
Intel 82845D Brookdale and 82801BA (ICH2) chipset
Support
184-pin DDR Module
Extend AGP Slot Support 4X AGP Support 1.5V VGA Card Only
Onboard Realtek RT8100 PCI LAN (845DBAL Only)
PC'99 Ready & PC'99 Colorful I/O Ports Design
Support USB Controller & PS/2 Mouse , Standard IR (infrared) Functio
Provide extra " three-wire" fans connectors
Magic Frequency Setting
Jumperless
CPU Vcore Voltage Minor Adustable in BIOS
BIOS Write Protect function to avoid Virus crash data
PC Health Monitoring On Post Screen
Magic Install
Y2K Compliant
ACPI Supporting For OS Directed Power Management
- Moden Ring remote wake up
- RTC alarm wake up
- Wake on LAN For OS
- Support software suspend & power
off
- Power Button Ride (Instant off or Delay
4 second power off)
SPECIFICATION
|
| Processor |
- Support
Socket 478B processor for Intel PentiumÒ 4 (mPGA478) package
processor ,Support 400MHz System Bus Frequency
|
| Chipset |
- Intel
82845 Brookdale memory Cotroller Hub (MCH)
- 82801BA
(ICH2) chipset (ICH2)
|
| CPU
Bus Frequency |
- CPU Bus Frequency , Choose One Step Add
1MHz From 100MHz Up to 132MHz in BIOS Setup (Frequency Magic Setting)
|
| Jumpless |
- Support Jumpless Function by BIOS SETUP
Let Users More Easier to Change The Frequency And Ratio
|
| Expansion
Slot |
- Five 32-bit PCI Bus Master Slots
- One CNR Slot
- One 4X AGP Slot (Support 1.5V AGP card
only)
|
| System
Memory |
- Support 2X 184 pin DIMM Socket Support
Max 2GB 2.5V unbuffered , DDR266/DDR200 SDRAM
|
| On
Board IDE |
- Support 2 X IDE Connectors for up to 4
IDE Drives
- Support PIO Mode 3 and Mode 4 and Bus
Master IDE DMA, Mode 4 Timing for up to 16M Bytes/s
- Support UTRA DMA-100 Bus Master IDE,
Provide faster transfer rate up to 100M Bytes/s
- Support LS-120 / ZIP Device
|
| On
Board Realtek RT8100 PCI Lan Controller (845DBAL only) |
- Reaktek RT8100 PCI Lan controller chip
- IEEE802.3 10/100 BASE T Standards
- BIOS Boot-up from Lan
|
| On
Board 3D Audio |
- Software Audio Controller With On Board
CODEC Complete to AC97'
- Support 3D Surround
- Support 3D Positioning
- Full Duplex Operation For Simultaneous
Record And Playback
- Sound Driver for Windows 95 , Windows98
& Windows NT4.0 , Media Rack
|
| On
Board Ultra I/O |
- On Board Winbond Chipset
- 2 X Serial Ports (16550 Fast UART
Compatible)
- 1 X Parallel Port (EPP and ECP
capabilities)
- 1 X Floppy Disk Connector (Supports 2
Floppy Drivers)
- 1 X PS2 Mouse Connector
- 1 X Keybord Cnnector
- 3 X Three Wire FAN Connector (Include
CPU FAN)
- 1 X LINE IN / LINE OUT / Microphone
Connector
- 1 X Game Port Connector (Support Two
Joysticks)
- 2 X Analog Audio CD Music line
Connectors (different connector)
- 1 X Consumer IR Connector
- 1 X Standard IR Connector (Infrared)
|
| Winbond
Hareware Doctor |
- Winbond Hareware Doctor to Track CPU
& SYSTEM Temperature, Voltage, Fan speed, Monitoring your Computer
- Driver For Win95/98
|
| On
Board USB |
- 4 X USB Ports Connector
- Support USB Keyboard & USB Mouse
|
| Power
Saving |
- ACPI/APM Power Management
- Moden Ring remote wake up
- RTC Alarm Wake up
- Support Software Suspend & Power
off
- Support Suspend to DISK
- Wake on LAN For OS
- Support Auto Power ON After Power Fail
Function
- Support Keyboard Password / Hot-Key /
Any Key Power on Function
- Support PS2 Mouse Button Click Power On
- Support Keyboard98 Power on Function
- Support Power Button Ride (Instant off
or Delay 4 second power off)
|
| Power
Supply |
- Support 20-pin ATX power supply (ATX-PW)
|
| BIOS |
- Award BIOS , Support Green function,
Plug and Play Function
- 2MBit Flash ROM
|
| Dimension |
- ATX Form Factor with 30.5cm X 21.0cm
|
