| SPECIFICATION |
| Processor |
- Support Socket-A for AMD Thunderbird /Duron TM uni-proccessor at
200/266MHz (830CN Ultra only) Front
Side Bus with double data rate
|
| Chipset |
- SiS 730SE single chip integrated a high performance North Bridge,
advance hardware 2D/3D GUI engine and South Bridge
|
| CPU Bus Frequency |
- CPU Bus Frequency , Choose One Step Add 1MHz From 66MHz Up to
166MHz in BIOS Setup (Frequency Magic Setting)
|
| Jumperless |
- Support Jumperless Function by BIOS SETUP Let Users More Easier to
Change The Frequency
|
| Expansion Slot |
- Three 32-bit PCI Bus Master slots
- One CNR Slot
|
| System Memory |
- Support 64 bit DRAM memory Interface (66/100/133MHz)
- Support 2Banks of SDRAM from 8Mbyte to 1GByte Main Memory
- 2 X 168-pins DIMM Sockets
|
| On Board IDE |
- Support 2 X IDE Connectors for up to 4 IDE Drives
- Support PIO Mode 3 and Mode 4 and Bus Master IDE DMA, Mode 4
Timing for up to 16M Bytes/s
- Support ULTRA DMA-100 Bus Master IDE, Provide faster transfer rate
up to 100M Bytes/s
- Support LS-120 / ZIP Device
|
| On Board AGP V.G.A |
- Advanced HW Acceleration for DVD playback
- Ultra-AGPTM Architecture
- UMA Architecture with 8/16/32/64 MB System Memory Sharable as
Display Memory
- Fully DirectX Compliant Engine
- Resolution up to 1920x1200 256/32K/64K/16M colour @80Hz NI
- VGA DRIVER Support Windows 95/98 and Windows NT 4.0 and Windows
2000
|
| On Board 3D Audio |
- Software Audio Controller With On Board CODEC Complete to AC97'
V2.1
- Support 3D Surround
- Support 3D Positioning
- Full Duplex Operation For Simultaneous Record And Playback
- Sound Driver for Windows 95 , Windows98 & Windows NT4.0 ,
Media Rack
|
| On Board Ultra I/O |
- 2 X Serial Ports (16550 Fast UART Compatible)
- 1 X Parallel Port (EPP and ECP capabilities)
- 1 X Floppy Disk Connector (Supports 2 Floppy Drivers)
- 1 X PS2 Mouse Connector
- 1 X Keyboard Connector
- 2 X Three Wire FAN Connector (Include CPU FAN)
- 1 X LINE IN / LINE OUT / Microphone Connector
- 1 X Game Port Connector (Support Two Joysticks)
- 2 X Analogue Audio CD Music line Connectors (different connector)
- 1 X Consumer IR Connector
- 1 X Standard IR Connector (Infrared)
|
| Winbond Hardware Doctor |
- Winbond Hardware Doctor to Track CPU & SYSTEM Temperature,
Voltage, Fan speed, Monitoring your Computer
- Driver For Win95/98
|
| On Board USB |
- 4 X USB Ports Connector
- Support USB Keyboard & USB Mouse
|
| Power Saving |
- ACPI/APM Power Management
- Modem Ring remote wake up
- RTC Alarm Wake up
- Support Software Suspend & Power off
- Wake on LAN For OS
- Support Power Button Ride (Instant off or Delay 4 second power
off)
|
| Power Supply |
- Support 20-pin ATX power supply (ATX-PW)
|
| BIOS |
- Award BIOS , Support Green function, Plug and Play Function
- 2MBit Flash ROM
|
| Dimension |
- Micro ATX Form Factor with 24.4cm X 21cm
|
