| SPECIFICATION |
| Processor |
- Socket 370 processor for Intel
Tualatin, PentiumÒ III Coppermine TM (FCPGA) , Celeron TM
(FCPGA) Processor,optimized for 133MHz Front Side Bus Frequency
- Support Cyrix III Series Processors
|
| Chipset |
- VIA 82C694T / 82C686B Chipset
|
| CPU
Bus Frequency |
- Support Jumper Select 66.7/100/133 MHZ
CPU Bus Frequency Default Selection
- CPU Bus Frequency , Choose One Step Add
1MHz From 66MHz Up to 166MHz in BIOS Setup (Frequency Magic Setting)
- Jumper Switch Selection CPU Ratio From
2X to 8X
|
| AGP Slot |
- Support AGP VGA Card for 1Gbytes/sec
data transfer rate and 66MHz Bus clock improve graphic function
- Support 4X Mode for AD and SBA Slot
|
| On Board 3D
Audio |
- Integraed 3D Positional Audio
Controller Compliant to AC97' V2.1
- Support 3D Surround
- Support 3D Positioning
- Full Duplex Operation For Simultaneous
Record And Playback
- Sound Driver for Windows 95 , Windows98
& Windows NT4.0 , Media Rack
|
| Expansion
Slot |
- One AMR Slot
- Five 32-bit PCI Bus Master Slots
- One 16bit ISA Bus Slot
|
| System
Memory |
- Support 3 Banks of SDRAM From 8MByte to
1.5 GByte
- 3 X 168-pins DIMM Scockets (3.3V)
- Support EDO (66MHz Only) & SDRAM
(66MHz/100MHz/133MHz) ,VCM DRAM
- Support ECC or Parity Check
|
| On Board
IDE |
- Support 2 X IDE Connectors for up to 4
IDE Drives
- Support PIO Mode 3 and Mode 4 and Bus
Master IDE DMA, Mode 4 Timing for up to 16M Bytes/s
- Support " Ultra DMA 100 "
Synchronous DMA Mode transfer rate up to 100M Bytes/s
- Support LS-120 / ZIP Device
|
| On Board
Ultra I/O |
- PC'99 Colorful I/O Ports Design
- 4 X USB Connectors
- 1 X Standard IR Connector (SIR)
- 2 X Serial Ports (16550 Fast UART
Compatible)
- 1 X Parallel Port (EPP and ECP
Capabilities)
- 1 X Floppy Disk Connector (Supports 2
Floppy Drives)
- 1 X PS2 Mouse / PS2 Keyboard Connector
- 2 X Three Wire FAN Connector (Include
CPU FAN)
- 1 X LINE IN Connector
- 1 X LINE OUT Connector 1 X MIC
Connector
- 1 X Game Port Connector
- 1 X SPDIF IN And OUT Connector
- 1 X Panasonic Analog Audio CD Music
line Connectors
- 1 X Sony Analog Audio CD Music line
Connector
|
| On Board
USB |
- 4 X USB Ports Connector
- Support USB Keyboard & USB Mouse
|
| Power
Saving |
- ACPI/APM Power Management
- Modem Ring Remote Wake up
- RTC Alarm Wake up
- Support Software Suspend & Power
off (Windows 95/98)
- Wake on LAN For OS
- Support Power Button Ride (Instant off
or Delay 4 second power off)
|
| Power
Supply |
- Support 20-pin ATX power supply (ATX-PW)
|
| BIOS |
- Award BIOS , Support DMI , Green ,
P&P Function
- 2MBite Flash ROM
- Support Full Screen Logo
|
| Dimension |
- ATX Form Factor with 30.5cm X 19cm
|
