| FEATURES |
| Support Socket-A for AMD Thunderbird
/Duron TM uni-proccessor at 200MHz Front Side Bus with double
data rate |
| VIA Apollo KT133(VT8363) System
controller and VT82C686A PCI to ISA bridge |
| On Board Hardware PCI Sound
Chip |
| Support 3 X 168 Pin DIMM Sockets
From 8Mbyte to 1.5GByte Main Memory |
| Support PCHEALTH MONITOR |
| Support Ultra DMA 33 / 66 Mode
|
| Meets PC 99 Requirements |
| Support USB Controller
& PS/2 Mouse , Standard IR (infrared) Function |
| Provide extra " three-wire"
fans connectors |
| Jumperless Design (BIOS Setup
CPU Bus Frequency) |
| Y2K Compliant |
| ACPI Supporting For OS Directed
Power Management |
| BIOS Auto Detect CPU voltage |
| Support Add CPU Voltage Select
in BIOS setup. From +0.05V ~ +0.3V(one step 0.05V)(Option) |
- Modem Ring remote wake up
- ATX power supply connector for Software Suspend & Show
Down power off
- Wake On LAN
- RTC Alarm Wake up
|
| SPECIFICATION |
| Processor |
- Support Socket-A for AMD Thunderbird
/Duron TM uni-proccessor at 200MHz Front Side Bus with double
data rate
|
| Chipset |
- VIA Apollo KT133(VT8363) System controller
and VT82C686A PCI to ISA bridge
|
| CPU Bus Frequency |
- BIOS Adjust CPU/PCI Bus Frequency ,
Include 100/100MHZ , 105/35MHZ , 112/37MHZ
|
| Expansion
Slot |
- One AMR Slot
- One 16-bit ISA Bus Slots
- Five 32-bit PCI Bus Master slots
|
| System
Memory |
- Support 64 bit DRAM memory Interface
(66/100/133MHz)
- Support 3 Banks of SDRAM from 8Mbyte
to 1.5GByte Main Memory
- Support SDRAM & Virtual Channel
SDRAM (VC SDRAM)
- 3 X 168-pins DIMM Sockets
|
| AGP SLOT |
- Support 4X AGP VGA Mode for 266MHz of
AD and SBA signalling
- Pipelined split transaction long-burst
transfers up to 1GB/sec
|
| On Board
IDE |
- Support 2 X IDE Connectors for
up to 4 IDE Drives
- Support PIO Mode 3 and Mode 4
and Bus Master IDE DMA, Mode 4 Timing for up to 16M Bytes/s
- Support ULTRA DMA-33/66 Bus Master
IDE, Provide faster transfer rate up to 33M/66M Bytes/s
- Support LS-120 / ZIP Device
|
| On Board
Hardware PCI sound chip |
- Fully Compliant AC97 Analogue I/O Component
- 48-Terminal TQFP package
- Multibit Converter Architecture for
improved S/N ratio greater than 90dB
- 16-Bit Stereo Full-Duplex Codec
- 4 Analogue Line-Level Stereo Input
- High Quality CD Input With Ground Sense
- Stereo Line Level Output
- Hardware Sound Blaster Pro for Windows
Dos box and real-mode DOS legacy compatibility
- Sound Driver for Windows 95/98 , Windows
2000 & Windows NT4.0 , Media Rack
|
| On Board
Ultra I/O |
- 2 X Serial Ports (16550 Fast UART Compatible)
- 1 X Parallel Port (EPP and ECP capabilities)
- 1 X Floppy Disk Connector (Supports
2 Floppy Drivers)
- 1 X PS2 Mouse Connector
- 1 X Keyboard Connector
- 2 X Three Wire CPU FAN Connector
- 1 X LINE IN / LINE OUT Connector
- 1 X Game Port Connector (Support Two
Joysticks)
- 2 X Analogue Audio CD Music line Connectors
(different connector)
- 1 X Standard IR Connector (Infrared)
|
| VIA Health Monitor |
- VIA Health Monitor to Track CPU Temperature,
Voltage, Fan speed , Monitoring your Computer
- Driver For Win95/98 and NT4.0
|
| On Board
USB |
- 4 X USB Ports Connector
- Support USB Keyboard & USB Mouse
|
| Power
Saving |
- ACPI/APM Power Management
- Modem Ring remote wake up
- RTC Alarm Wake up
- CPU Fan Auto-Stopping in Suspend Mode
- Support Software Suspend & Power off
(Windows95 or Windows98)
- Wake on LAN For OS
- Support Power Button Ride (Instant
off or Delay 4 second power off)
|
| Power
Supply |
- Support 20-pin ATX power supply (ATX-PW)
|
| BIOS |
- Award Plug and Play and Green Function,
Full screen logo support
- 2MByte Flash ROM
|
| Dimension |
- ATX Form Factor with 30.5cm X 21cm
|
