| FEATURES |
| Support Socket 370 processor
for Intel PentiumÒII / III , Celeron TM
,Coppermine TM (FCPGA,PPGA) Processor |
| Intel 82815 And 82801AA Chipset
|
| Intel GMCH Build-in High Performance
AGP V.G.A |
| Software Audio Controller With
On Board CODEC Compliant to AC97' |
| Support Ultra DMA 66 & Bus
Master IDE Mode & PIO Mode |
| Support PC HEALTH MONITOR |
| Support 3 X 168 Pin DIMM Sockets
From 8Mbyte to 512MByte Main Memory |
| Meets PC 99 Requirements |
| Support USB Controller & PS/2
Mouse , Standard IR (infrared) Function |
| Provide extra " three-wire"
fans connectors |
| Support Keyboard Password /
hot-key / Any-key & PS/2 mouse button click & Keyboard98 Power on Function |
| Jumperless Design (BIOS Setup
CPU Bus Frequency and CPU Ratio) |
| Y2K Compliant |
| ACPI Supporting For OS Directed
Power Management |
- Modem Ring remote wake up
- Power Button Ride (Instant off or Delay 4 second power
off)
- RTC alarm wake up
- Wake on LAN For OS
- Support software suspend & power off (Windows 95 or
Windows98)
|
| SPECIFICATION |
| Processor |
- Socket 370 processor for Intel PentiumÒII
/ III , Celeron TM ,Coppermine TM (FCPGA,PPGA)
Processor, optimized for 133MHz Front Side Bus Frequency
|
| Chipset |
- Intel 82815 Graphics And Memory Controller
HUB (GMCH)
- Intel 82801AA I/O Controller HUB
- Support Dynamic Video Memory (DVM)
Technology
|
| CPU Bus Frequency |
- Support Jump Select 66.7/100/133 MHZ
CPU Bus Frequency
- CPU Bus Frequency , Choose 66 / 75
/ 83 / 95 / 100 / 112 / 117 / 124 / 133 / 140 / 150 MHZ in BIOS Setup
- CPU Ratio Selection For 2 , 2.5 , 3
, 3.5 , 4 , 4.5 , 5 , 5.5 , 6 , 6.5 , 7 , 7.5 , 8 in BIOS Setup
|
| Jumperless |
- Support Jumperless Function by BIOS SETUP
Let Users More Easier to Change The Frequency And Ratio
|
| Expansion
Slot |
- Five 32-bit PCI Bus Master Slots
- One AMR (Audio/Modem Riser) Slot
- One 4X AGP/AIMM Slot
|
| System
Memory |
- Support 3 Banks of SDRAM from 8MByte
to 256MByte or 512MByte Main Memory
- 3 X 168-pins DIMM Sockets
- Non-ECC PC-100/PC-133 SDRAM
|
| On Board
IDE |
- Support 2 X IDE Connectors for
up to 4 IDE Drives
- Support PIO Mode 3 and Mode 4
and Bus Master IDE DMA, Mode 4 Timing for up to 16M Bytes/s
- Support ULTRA DMA-66 Bus Master
IDE, Provide faster transfer rate up to 66M Bytes/s
- Support LS-120 / ZIP Device
|
| On Board AGP V.G.A |
- Support AGP2.0 including 4x AGP data
transfers
- 8M Frame Buffer DVMT (Dynamic Video
Memory Technology)
- Intel GMCH Built-in Graphics supports
up to 1280x1024x24 bit 85Hz
- Support Flexible AGP In-Line Memory
Module (AIMM) card increase 3D performance
- Support DirectX5 / DirectX6 & Software
MPEG XING driver
- VGA DRIVER Support Windows 95/98 and
Windows NT 4.0 and Windows 2000
|
| On Board
3D Audio |
- Software Audio Controller With On Board
CODEC Complete to AC97'
- Support 3D Surround
- Support 3D Positioning
- Full Duplex Operation For Simultaneous
Record And Playback
- Sound Driver for Windows 95 , Windows98
& Windows NT4.0 , Media Rack
|
| On Board
Ultra I/O |
- On Board ITE 8712F Chipset
- 2 X Serial Ports (16550 Fast UART Compatible)
- 1 X Parallel Port (EPP and ECP capabilities)
- 1 X Floppy Disk Connector (Supports
2 Floppy Drivers)
- 1 X PS2 Mouse Connector
- 1 X Keyboard Connector
- 3 X Three Wire FAN Connector (Include
CPU FAN)
- 1 X LINE IN / LINE OUT Connector
- 1 X Game Port Connector (Support Two
Joysticks)
- 2 X Analogue Audio CD Music line Connectors
(different connector)
- 1 X Consumer IR Connector
- 1 X Standard IR Connector (Infrared)
- 1 X VGA Connector
|
| PC Health Monitor IIII |
- PC Health Monitor IIII to Track CPU
& SYSTEM Temperature, Voltage, Fan speed, Monitoring your Computer
|
| On Board
USB |
- 4 X USB Ports Connector
- Support USB Keyboard & USB Mouse
|
| Power
Saving |
- ACPI/APM Power Management
- Modem Ring remote wake up
- RTC Alarm Wake up
- Support Software Suspend & Power off
(Windows95 or Windows98
- Support Suspend to DISK
- Wake on LAN For OS
- Support Auto Power ON After Power Fail
Function
- Support Keyboard Password / Hot-Key
/ Any Key Power on Function
- Support PS2 Mouse Button Click Power
On
- Support Keyboard98 Power on Function
- Support Power Button Ride (Instant
off or Delay 4 second power off)
|
| Power
Supply |
- upport 20-pin ATX power supply
(ATX-PW)
|
| BIOS |
- Intel 82802AB Firmware HUB
- Award BIOS , Support Green function,
Plug and Play Function
- 4MByte Flash ROM
|
| Dimension |
- ATX Form Factor with 30.5cm X 19cm
|
